Road Track Trials





Displacement: 249.5 ccm (15.22 cubic inches)
Engine type: Single cylinder, two-stroke, Direct reed valve VForce 4
Bore x stroke: 72.0 x 72.0 mm (2.8 x 2.8 inches)
Fuel system: Carburettor. Kehin PWK 38
Ignition: Digital CDi
Cooling system: Liquid
Gearbox: 6-speed
Transmission type: Chain   (final drive)Clutch Multidisc in oil bath. Magura clutch pump.
Emission details: Euro 5
Exhaust system: Tecnigas
Frame type: Central spine in Chromium Molybdenum Steel. Aluminum subframe.
Front suspension: KYB 48 mm, AOS System, Closed Cartridge Anti-Friction Treatment DLC
Front wheel travel: 300 mm (11.8 inches)
Rear suspension: Shock absorber with gas tank KYB
Rear wheel travel: 131 mm (5.2 inches)
Front tire: 90/90-21
Rear tire: 140/80-18
Front brakes: Single disc. Nissin Clamp and Pump Assembly
Diameter: 260 mm (10.2 inches)
Rear brakes: Single disc. Nissin Clamp and Pump Assembly
Diameter: 200 mm (7.9 inches)
Wheels: Goldspeed Pro, aluminium alloy, wire spoked. Michelin Enduro Medium tires.
Seat: Non-slip bicolor Enduro Pro
Dry weight: 105.0 kg (231.5 pounds)
Seat height: 950 mm (37.4 inches) If adjustable, lowest setting.
Overall height: 1235 mm (48.6 inches)
Overall length: 2145 mm (84.4 inches)
Overall width: 810 mm (31.9 inches)
Wheelbase: 1480 mm (58.3 inches)
Fuel capacity: 9.80 litres (2.59 US gallons)
